Differential pressure transmitter - CP114-115
Backorder Now, once ordered your item will dispatch before the 17th of October 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
$329.67 AUD Inc. GST
Features:
- Ranges from -500/+500 mbar to -2000/+2000 mbar (according to models)
- Configurable intermediary ranges
- 0-10 V or 4-20 mA output, active, power supply 24 Vac/Vdc (3-4 wires) or 4-20 mA
output, passive loop, power supply from 16 to 30 Vdc (2 wires)
- ABS V0 housing, IP65, with or without display
- turn system mounting with wall-mount plate
- Housing with simplified mounting system
Specifications
|
Unit of measurement |
mbar, inWG, mmHG, PSI, mmH2O, daPa, hPa, kPa |
|
Accuracy* |
1.5% of reading 3 mbar |
|
Response time |
1/e (63%) 0.3 s |
|
Resolution |
1 mbar ; 0.1 inWG ; 1 mmHG ; 1 mmH2O ; 1 hPa ; 10 daPa ; 0.1 kPa ; 0.1 PSI |
|
Auto zero |
Manual with push-button |
|
Type of fluid |
Air and neutral gases |
|
Overpressure tolerated |
CP114 : 1400 mbar CP115 : 4100 mbar |
|
Operating temperature |
From 0 to +50 C |
|
Storage temperature |
From -10 to +70 C |
| CP11 | + |
Measuring range 4= -500/+500 mabr 5= -2000/+2000 mbar |
+ | Power supply / Output A= Active 24 Vac/Vdc 0-10 V or 4-20 mA P= Passive 16/30 Vdc 4-20 mA |
+ |
Display O= with display N= without display |
Protection : IP65
Display : LCD 10 digits. Size : 50 x 17 mm
Height of digits : Value : 10 mm ; Unit : 5 mm
Connections : safety 6.2 mm
Cable gland : for cables 8 mm maximum
Weight : 143 g
