FLIR 600A Power Clamp

ORDER ME IN
Product code: IC-CM83

Backorder Now, once ordered your item will dispatch before the 11th of May 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).

The FLIR CM83 is an industrial-grade power clamp meter engineered with advanced power analysis, harmonics measurements, and variable frequency drive (VFD) filtering functions to meet the needs of electrical troubleshooters.

Read more

$595.00 AUD + GST
 $654.50 AUD Inc. GST

The FLIR CM83 is an industrial-grade power clamp meter engineered with advanced power analysis, harmonics measurements, and variable frequency drive (VFD) filtering functions to meet the needs of electrical troubleshooters.

The meter features Bluetooth technology to connect compatible mobile devices for remote viewing and sharing, and METERLiNK technology to wirelessly embed electrical readings into radiometric infrared images on compatible FLIR thermal cameras.
Features:
- Superior accuracy: The True RMS clamp meters provide VFD Mode for superior accuracy while working on VFD-controlled equipment, and advanced power efficiency and harmonics measurements enable system-level performance analysis.
- Reliable performance: Features Inrush mode to capture AC Current spikes during start-up, and phase-rotation testing to ensure motor and power source alignment.
- View data remotely, share instantly: View readings from your mobile device via Bluetooth; METERLiNK technology wirelessly embeds data into thermal images on compatible FLIR cameras.

Specifications

- Jaw Opening: 37 mm (1.45", 1000MCM)
- Warranty: Limited Lifetime
- Certifications: CE, UL, FCC
- Bluetooth range max: 32 ft (10 m)
- Gallery: 17555
- AC VFD Voltage: Range 1000 V/ Basic Accuracy +/- 1%
- AC/DC Current: Range 599.9 A / Basic Accuracy +/- 2%
- AC/DC Voltage: Range 999.9 V / Basic Accuracy +/- 1% / 0.7%
- Active Power: Range 9.999 kW to 599.9 kW, (10 V, 5 A min) / Basic Accuracy +/- 3%
- Capacitance: Range 3.999 mF Max / Basic Accuracy +/- 1.9%
- Category Rating: CAT IV-600V, CAT III-1000V
- Continuity Threshold: Range 30 ohm / Basic Accuracy +/- 1%
- Diode Test: Range 0.4 to 0.8 V / Basic Accuracy +/- 0.1V
- Frequency: Range 20.00 Hz to 9.999 kHz / Basic Accuracy +/- 0.5%
- Harmonics: Range 1st-25th Order / Basic Accuracy +/- 5%
- Inrush Current: Range 599.9 ACA Max (Integration Time 100 ms) / Basic Accuracy +/- 3%
- Resistance: Range 99.99 kiloohm Max / Basic Accuracy +/- 1%
- Total Harmonic Distortion: Range 0.0 to 99.9% / Basic Accuracy +/- 3%
