High Temperature Pressure Data Logger With Flush Top

ORDER ME IN
Product code: PR140-Flush

Backorder Now, once ordered your item will dispatch before the 21st of May 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).

The PR140 is a pressure data logger designed for use in autoclave validation and mapping. This rugged data logger can withstand temperatures up to 140 C and is completely submersible (IP68).

Read more

$2,809.85 AUD + GST
 $3,090.84 AUD Inc. GST
This high temperature and pressure Data Logger comes with a Flush Top.

The PR140 is a pressure data logger designed for use in autoclave validation and mapping. This rugged data logger can withstand temperatures up to 140C and is completely submersible (IP68).
The PR140 is built with a precision stainless steel pressure gauge. The data logger has an accuracy of 0.03 Bar (0.435 PSI), which can be achieved over a wide temperature range, from 20C to +140C (68F to 284F). The PR140 can be programmed to take readings as often as once per second (1Hz), and has non-volatile memory that can store up to 32,700 measurements.

The PR140 data logger is easy to use. Simply place it in the IFC400 docking station, connect to a computer, and the device can be started, stopped or downloaded using the MadgeTech software. Graphical, tabular and summary data is provided for analysis and can be viewed in PSIA, mmHg, bar, Torr and kPa. The data can also be automatically exported to Excel for further calculations.

Required Product:
The following accessories may be required to connect this data logger to your computer.


Specifications

Pressure Sensor

Semiconductor (strain gauge)

Pressure Range (Nominal)

0 to 5 Bar (0 to 72.5 PSIA)

Pressure Resolution

0.1m Bar (0.0015 PSIA)

Pressure Response Time

0.1ms (10 to 90% FSR)

Repeatability

0.5% FSR;0.2% typical

Calibrated Accuracy

0.03 Bar (0.435 PSI), 20C to +140C (68F to 284F)

Memory

32,700 readings; software configurable memory wrap

Reading Rate

1 second to once every 24 hours

Required Interface Package

IFC400

Baud Rate

125,000 baud

Typical Battery Life

2 years

Operating Environment

-20C to +140C (-4F to +284F);

0 to 100%RH

Note: The PR140 may be used above 60C for up to 8 hours, per 24 hour period.

Submersible / IP Rating

Yes / IP68

Approvals

CE

Dimensions:
50.8mm x 25.4mm dia
Weight: 85 g
