HM110-PND Humidity Transmitter
Backorder Now, once ordered your item will dispatch before the 09th of May 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
The HM110 is a humidity transmitter with a measurement range from 5 to 95%RH. This model has a duct probe with no display and passive 16/30 Vdc – 4-20 mA power.
Regular price
$349.10 AUD
+ GST
$384.01 AUD Inc. GST
$384.01 AUD Inc. GST
The HM110 is a humidity transmitter with a measurement range from 5 to 95%RH. This model has an ambient probe with no display and active 124 Vac/Vdc 0-10 V power.
2 Year Warranty (1 Year Manufacturer Warranty + Bonus 1 Year Instrument Choice Warranty)
HM110-PNA Features
- Measuring range from 5 to 95%RH
- 16/30 Vdc 4-20 mA passive power
- ABS V0 housing IP65 (duct or remote model) or IP20 (ambient model), with or without display
- turn system mounting with wall-mount plate
- Housing with simplified mounting system
Specifications
Measuring range
|
from 5 to 95% RH
|
Accuracy
|
2% RH (if 15C T 25C) on ambient model
|
Response time
|
4s
|
Resolution
|
0.1% RH
|
Drift linked to temperature
|
0.04 x (T-20) %RH (if 15C T 25C)
|
Type of sensor
|
Capacitive
|
Resolution
|
0.1% RH
|
Factory adjustment uncertainty
|
0.88% RH
|
Type of fluid
|
Air and neutral gases
|
Display:
|
LCD 10 digits. Size: 50 x 17 mm
|
Height of digits:
|
Value: 10 mm ; Unit: 5 mm
|
Cable gland:
|
for cables 8 mm maximum
|
Cable of remote probes:
|
length 2 m and 4.8 mm in silicone
|
