MK350S Premium Handheld Spectrometer
Backorder Now, once ordered your item will dispatch before the 11th of May 2025, call 1300 737 871 (NZ 0800 737 871 to confirm).
The MK350S is a multi-industrial spectrometer featuring 40 light measurement units. Applicable to quality control, interior light designers and cinematographers. It can also measure PPFD (Photosynthetic photo flux), functioning as a Lux meter for plants.
Regular price
$5,920.00 AUD
+ GST
$6,512.00 AUD Inc. GST
$6,512.00 AUD Inc. GST
The advanced MK350S is the 1st handheld Spectrometer applicable to different industries. It had more than 40 light measurement units which are CCT, LUX, CRI, CIE1976, CIE1931,PPF, CQS, Duv, LambdaP, S/P ratio, TLCI, GAI. Appropriate for RD lighting designers, lighting manufactory and quality control, interior light designers, horticulture measurement, cinematographer and health prevention.
The MK350S is also a LUX meter for Human, Quantum Meter, Light Grow Meter and PPF Meter (Photosynthetic Photo Flux) for plants. MK350S can measure PPFD at different range wavelength for horticulture to determine if certain plants are receiving the appropriate amounts of light at the right colors.
Specifications
Spectrum:
- Sensor: CMOS Linear Image Sensor
- Illuminance meter class: Directional response conforms to JIS C 1609-1:2006 for General Class AA. Directional response conforms to DIN 5032 Part 7 Class B.
- Wavelength Range: 380 to 780 nm
- Wavelength Data Increment: 1 nm
- Spectral Bandwidth: Approximately 12 nm (Half Bandwidth)
- Wavelength Reproducibility: +/- 1 nm
- Measurement Range: 1 to 150,000 lx
- Stray light: -25 dB max.
- Integration Time Range: 60us to 5,000 ms
- Digital Resolution: 16 bits
Flicker:
- Measurement Range: 1 to 150,000 lx
- Sampling Rate: 100k sample/sec
- Frequency Range: 5 to 50k Hz
- Frequency Resolution: 2, 4, 8, 16, 32 Hz
- Flicker Accuracy: +/- 5%
Measuring modes:
- Basic Mode
- Spectrum Mode
- CRI Mode
- CIE 1931 / 1976 Chromaticity Mode
- LUX Image Distribution Mode
- Log Mode
- BIN Chart Mode
- Quality Control Checker Mode
- Measurement Comparison Mode
- Transmit Mode
- TM-30-15 Mode
- Flicker Mode
- Frequency Mode
- Flicker Risk Mode
- Blue Light Hazard Mode
- Browser Mode
- Option Mode
System configurations:
- Display: 4.3" 800X480 Resistive Touch LCD
- Max. files: 21,000 Files at 8GB SD Card (Excel + JPG)
- Battery Operation time: less than or equal to 4 hours / Fully Charged
- Power: Adapter; 2500 mAh (3.7V Rechargeable Li-ion Battery)
- Data Output Interface SD: SD Card (SD2.0,SDHC/up to 32G) / Mini USB Port (USB 2.0) / WiFi SD Card compatible with iOS and Android (Android app not ready yet)
- Data Format: Compatible Excel / JPG
- Dimensions: 163 x 81 x 26.6 mm (H x W x D)
