Eight Channel, Low Level Dc Voltage Data Logger, 0 - 30V
Unfortunately, the OctVolt-30V has been discontinued, check out our other Voltage Loggers for more options.
The device accepts voltage signals from sensors, transducers and many other common voltage sources and features user-programmable Engineering Units and offset/gain calculations so input voltages can be scaled to proper units being measured. For example, a flow rate sensor with a voltage output can be displayed as flow rate in the software graph and data. The storage medium is non-volatile solid state memory, providing maximum data security even if the battery becomes discharged. The device can be started and stopped directly from your computer and its small size allows it to fit almost anywhere. The OctVolt makes data retrieval quick and easy. Simply plug it into an empty COM or USB port and our user-friendly software does the rest.
0 - 30V Range
Specifications
Voltage
Voltage Range |
0 to 30VDC |
|---|---|
Voltage Resolution |
0 to 30VDC:1.0mVDC |
Voltage Calibrated Accuracy |
0 to 30VDC: 0 to 2.5 and 0.10%FSR at 25C |
General
Memory |
16,383/channel |
|---|---|
Reading Rate |
1 second up to 12 hours |
Baud Rate |
2,400 |
Channels |
4 |
LED Indicators |
Red |
Battery Life |
1 year |
Material |
Anodized aluminum |
Dimensions |
3.5" x 4.4" x 1.5" (89mm x 112mm x 39mm) |
Operating Environment |
-20~+60C, 0~95%RH non-condensing |
Required Interface Package |
IFC110 or IFC200 |
Product Tables
Range |
0 to 30 VDC |
|---|---|
Accuracy |
0.10%FSR at 25C |
Resolution |
1.0mVDC |
